Building a Pressure Washing Trailer Rig

Trailer Selection: Size and Capacity

A pressure washing trailer’s payload capacity determines what you can carry. Total weight includes the trailer itself, water tank, pump/engine, hose reel, and misc. equipment.

Trailer Size Options:

Single-Axle Trailers (2,000–3,500 lbs GVWR):

• 5’ x 8’ or 6’ x 10’ deck
• Best for: small teams, limited water/chemical capacity
• Weight budget: ~1,200 lbs after frame, deck, and equipment
• Typical load: 300–500 gal water tank, single pressure washer
• Towing vehicle: 1/2-ton pickup minimum

Tandem-Axle Trailers (7,000–14,000 lbs GVWR):

• 6’ x 12’ or 8’ x 16’ deck
• Best for: multi-person crews, high-volume water needs
• Weight budget: ~3,000–5,000 lbs after frame and deck
• Typical load: 1,000+ gal water tank, dual pumps, or hot water unit
• Towing vehicle: 3/4-ton or 1-ton pickup required

Budget Breakdown by Size:

Budget Tier ($3,000–$6,000):

• 6’ x 10’ single-axle trailer, used ($1,000–$2,000)
• 300 gal plastic tank ($300–$500)
• One 3.5 GPM prosumer pressure washer ($1,000–$1,500)
• Minimal hose reel, PVC plumbing

Mid Tier ($8,000–$15,000):

• 8’ x 12’ tandem-axle trailer, new ($3,000–$5,000)
• 500 gal polyethylene tank ($800–$1,200)
• One 4+ GPM professional washer ($2,000–$3,000)
• Steel hose reel, brass fittings, electrical 12V battery system

Professional Tier ($18,000–$35,000+):

• 8’ x 16’ custom tandem-axle, new ($5,000–$8,000)
• 1,000+ gal tank system ($2,000–$4,000)
• Dual 4 GPM washers OR one hot water unit ($4,000–$8,000)
• Integrated hose reel, full plumbing loop, 12V electrical with generator, chemical injection

Water Tank Placement and Selection

Tank Material:

• Polyethylene (plastic): Durable, rust-proof, most common. Cost: $1–$3/gallon
• Steel: Heavy, prone to rust, but extremely durable. Cost: $0.75–$1.50/gallon. Requires interior epoxy coating
• Fiberglass: Strong, lightweight, good lifespan. Cost: $2–$4/gallon

For most new builds, polyethylene is the best choice—lightweight, affordable, and maintenance-free.

Tank Size Guidelines:

• 300 gal: Single small operator, frequent water source access
• 500 gal: One operator, 4–6 hours runtime without refill
• 750 gal: Two-person crew, most common for mobile crews
• 1,000+ gal: High-volume operations, stationary sites, chemical operations

Tank Placement on Trailer:

• Center the tank over the trailer’s axles for balanced weight distribution
• Lower the tank as much as possible (center of gravity matters for towing stability)
• Secure the tank with lag bolts or welded straps; it must not shift under acceleration/braking
• Leave clearance for hose connections and drainage valve access

Tank Connections:

• Install a fill cap (4” opening typical) with strainer screen to keep debris out
• Add a drain valve at the lowest point; ball valve (not petcock) for reliability
• Install a water level gauge (external sight tube) so operators know when to refill
• Use 3/4” NPT ports for pump inlet and overflow line

A 500-gallon tank takes 15–20 minutes to fill at typical garden hose speed (5 GPM). Plan refill time into your service estimates.

Pump and Engine Mounting

Pump/Engine Assembly Weight:

• Prosumer (3.5 GPM): 150–180 lbs
• Professional (4–6 GPM): 200–280 lbs
• Dual pump setup: 400–500 lbs

Mounting Platform:

• Build a sturdy steel sub-frame, welded to the trailer frame
• Mount the pressure washer on engine isolation mounts (rubber blocks) to reduce vibration
• Position 18–24 inches forward of the tank, leaving room for hose connections
• Ensure adequate cooling air flow around the engine (don’t box it in)

Engine Fuel Tank:

• Typically 5–7 gallon integral tank on the engine
• Single tank provides 4–8 hours runtime depending on load
• Consider adding a remote fuel tank (10–20 gal) for extended jobs with a gravity-feed line to the engine
• Use a fuel shut-off valve between remote tank and engine to prevent siphoning

Securing the Pump:

• Bolt down with 3/8” bolts through the engine block
• Vibration will work bolts loose; use thread-locking compound and check monthly
• Ensure the pump exhaust pipe is clear and pointed away from operator position

Plumbing Layout

Water Supply Line (Tank to Pump):

• Use 3/4” vinyl suction hose with stainless steel reinforcement (not garden hose)
• Keep suction line as straight and short as possible (under 10 feet)
• Route it low, avoiding loops that trap air
• Install a 2-mesh strainer basket at the tank outlet to prevent debris from entering the pump
• Slope the suction hose slightly downward from tank to pump

Discharge Plumbing (Pump to Gun):

• Use high-pressure hose rated for your PSI plus 25% safety margin (3000 PSI washer = 3750 PSI rated hose minimum)
• Mount a ball valve immediately after the pump for safety (cuts pressure instantly if needed)
• Install a pressure gauge (0–4000 PSI range) on the discharge to monitor output
• Run hose to a hose reel or coil-down storage
• Use stainless steel quick-disconnect couplings for fast gun/nozzle changes
• Color-code hoses: blue for inlet, red/black for outlet

Chemical Injection (if applicable):

• Use a 3/4” NPT T-fitting before the pump inlet (upstream) OR after discharge (downstream)
• Downstream injection (via venturi injector) is safer and allows flow-through chemical rinsing
• Run chemical supply line through a 3/8” vinyl suction hose with check valve to prevent backflow
• Mount the chemical tank vertically, lower than pump inlet, with drain valve

Electrical 12V System

A basic 12V system powers lights, a small pump for chemical circulation, and optional air compressor for brake actuators.

Battery:

• 8D or larger marine battery (battery bank recommended for 200+ amp-hour capacity)
• House in a vented enclosure bolted to the trailer frame
• Install a disconnect switch (large lever switch) for safety when parked

Wiring:

• 2-gauge battery cable from battery to main disconnect, then to loads
• Main breaker/fuse (100 amp) immediately after disconnect
• Individual fuses (10–20 amp) for each circuit (lights, pump, compressor)
• Use tinned marine-grade wire (resists corrosion better than automotive wire)
• Route wiring through protective conduit, away from moving parts

Typical 12V Loads:

• LED work lights (20–40 amp draw, 5–10 minutes runtime)
• Chemical transfer pump (5–10 amp, intermittent use)
• Air compressor (30–50 amp, 10–20 minutes runtime)
• Trailer lights (5 amp continuous)

For extended operation (generator recommended):

• A small 3kW portable generator ($400–$800) powers 110V tools and trickle-charges the battery system

Grounding:

• Connect all equipment frames to a common ground point (battery negative terminal)
• This prevents electric shock if anyone touches dissimilar metals

Hose Reel Positioning and Design

Reel Type Options:

Manual Hand-Crank Reel:

• Low cost ($300–$600)
• Suitable for 100–200 foot hoses
• Requires physical effort; winding 200 feet takes 3–5 minutes
• Best for: single operators who don’t mind the effort

Spring-Tension Reel:

• Spring-loaded, helps with manual rewinding
• Cost: $500–$1,000
• Faster than pure manual
• Best for: small crews wanting some ease without electrics

Electric Motor Reel:

• 12V motor powered from trailer battery
• Cost: $1,200–$2,500
• One button rewind in 1–2 minutes
• Drawback: battery drain (not viable for all-day operation without charge)
• Best for: high-volume operations where time savings matter

Hose Reel Placement:

• Mount on the rear of the trailer, low and centered
• Position within arm’s reach of the operator station
• Ensure full reel rotation doesn’t interfere with trailer lights or other equipment
• Leave 3–4 feet clearance behind the trailer for unspooling hose

Reel Capacity:

• 3/8” diameter hose: 100–200 feet typical
• 1/2” diameter hose: 150–250 feet typical

A 200-foot hose weighs 60–80 lbs fully loaded; an electric reel is worth the cost if you’re spooling daily.

Quick-Disconnects and Couplings

Invest in quality quick-disconnects to save time and prevent spills:

• Use flat-face couplers (prevent drips when disconnected)
• Color-code: blue for inlet, red for discharge
• Install on gun, reel, and pump discharge
• Cost: $50–$150 per set, but time savings are worth it

Drainage and Cleanup

• Install a drain point at the lowest corner of the trailer frame
• Use a ball valve connected to a 3/4” hose that can route water away
• Never drain into storm drains; collect runoff for proper disposal
• For chemcial operations, collect and contain all wastewater

Weighing and GVWR Verification

Before first use:

1. Fill the water tank completely
2. Load all equipment, tools, chemical
3. Drive to a CAT scale and weigh the loaded trailer
4. Subtract the empty trailer weight (from registration/build sheet)
5. Compare to GVWR

If overloaded, remove weight or upgrade to a larger trailer.
